Railway Flat Trailer Carts
Our products include six series transfer trolleys(KPD Series, KPX Series, KPJ Series and KPT Series) with the load from 1ton-300tons. Strong designing group can design all kinds of special standard transfer carts, such as turning transfer carts, hand trolley, mining industry using flat trolley, crane, crane trolley, crane parts, ladle transfer trolley, climbing capacity, simple operation, long driving range, low noise, easy maintenance and easy remote control without wire
KPDZ series railway flat carts are powered by the low voltage electricity from the railways. The power source AC 380V is transformed into AC 36V two-phase and are respectively connected to the two rails. Then the flat trolley’s wheels conduct the AC36V on rail into the electrical appliance box at the bottom of the carts. And then the AC 36V is transformed into DC 36V and then control the DC and adjust the speed and so on. KPDZ flat carts can be used both on the ‘S’ and arc-shaped railways. They also can be used in the high-temperature environment. The hydraulic lifting device can be installed on the flat carts.
KPDS series’ railway flat carts are powered by the low voltage electricity from the railways. The power source AC 380V is transformed to AC 36V three-phrase through transformer. Then they are connected to the three rails respectively(add a conducting rail). The flat carts’ wheels and conducting plate lead the AC 36V electricity to the electrical appliance box which is installed on the carts. And AC 36V is transformed to AC 380V through the transformer. Then controls AC Metallurgy motor through AC control system to make the transfer cart start, stop, go forward and backward and so on. This series’ transfer cart can be used both on “S” and arc-shaped rails, and high temperature.
KPC series’ rail transfer carts are powered by the sliding line. It conducts AC 380V sliding wire directly into the AC electrical control system of the transfer cart to let it start, stop, go forward and backward and so on. The cart gets power from the slider of the safe sliding line which is moved by the cart’s running. The sliding line is limited by the installation position. It can be installed between the two rails or in the channel outside the track. For your safety and convenience, you can add boards on the channel. Through the automatic device to conduct the power in the channel directly to the rail cart. The operation system is low voltage 36V power. The hydraulic lifting device can be installed on the flat carts.
