Brief introduction for KPDS series' railway flat carts poweredby low voltage electricity from the railways.

KPDS series' railway flat carts are powered by the low voltage electricity from the railways. The power source AC 380V is transformed to AC 36V three-phrase through transformer. Then they are connected to the three rails respectively(add a conducting rail). The flat carts' wheels and conducting plate lead the AC 36V electricity to the electrical appliance box which is installed on the carts. And AC 36V is transformed to AC 380V through the transformer. Then controls AC Metallurgy motor through AC control system to make the transfer cart start, stop, go forward and backward and so on. This series' transfer cart can be used both on “S” and arc-shaped rails, and high temperature. There can be attached with hydraulic elevator system and lifting system. The cart has the vantages of safety and flexibility. But this series have strict requirement on the construction of the railways which need to be insulated. This series' transfer carts are suitable for the environment of heavy load capacity(>50t),high using frequency and not too short running distance. It is not limited by running distance, but if the running distance exceeds 70m,you need to increase the transformers to make up the voltage which has been lowered.

Specification

Technical Parameters for KPDS Series Rail Carts Powered by Conducting Rail

Model		KPDS-2t	KPDS-5t	KPDS-10t	KPDS-16t	KPDS-20t	KPDS-25t	KPDS-30t	KPDS-40t	KPDS-50t	KPDS-63t	KPDS-80t	KPDS-100t	KPDS-150t
Rated load(t)		2	5	10	16	20	25	30	40	50	63	80	100	150
Table size(mm)	Length	2000	3500	3600	4000	4000	4500	4500	5000	5500	5600	6000	6500	10000
	Width	1500	2000	2000	2000	2200	2200	2200	2500	2500	2500	2600	2800	3000
	Height	450	450	500	500	550	600	600	650	650	750	800	850	1200
Wheel Base(mm )		1200	2500	2600	2800	2800	3200	3200	3800	4200	4300	4700	4900	7000
Rail Inner Gauge(mm)		1200	1435	1435	1435	1435	1435	1435	1435	1435	1435	1800	2000	2000
Wheel Diameter(mm)		Ф270	Ф300	Ф300	Ф 350	Ф 350	Ф400	Ф 400	Ф500	Ф500	Ф 600	Ф600	Ф600 (Heavy)	Ф 600
Wheel Quantity		4	4	4	4	4	4	4	4	4	4	4	4	8
Ground Clearance(mm)		50	50	50	50	50	50	50	50	50	75	75	75	75
Running Speed(mm)		0-25	0-25	0-25	0-20	0-20	0-20	0-20	0-20	0-20	0-20	0-20	0-20	0-18
Motor Power(kw)		0.8	1.5	1.5	2.2	2.5	3	4	5.5	5.5	7.5	7.5	11	15
Transformer Power(KVA)		3	5	5	6.8	6.8	6.8	10	10	10	20	20	30	30
Transformer Quantiry(Pcs)		1	1	1	1	1	1	1	1	1	1	1	1	1
Running distance(m)		80	80	80	80	80	80	80	60	50	50	50	50	50
Max Wheel Load(KN)		14.4	25.8	42.6	64.5	77.7	94.5	110.4	142.8	174	221.4	278.4	343.8	265.2
Reference Weight(t)		2.8	3.6	4.2	5.5	5.9	6.5	6.8	7.6	8	10.8	12.8	14.6	26.8
Recommended Rail Model		P15	P18	P18	P24	P24	P38	P38	P43	P43	P50	P50	QU100	QU100

Notes:

1.Load Capacity, table size and rail gauge can be customized.

2. Options:

a. Remote radio control(imported or made in China);

b. Automatic stop when detecting obstacle or person, limit switches(to limit travel);

c. Automatic cutting off power on rail;

3. Variale speed device(VFD);

4.Electrical parts can be optional(made in China or imported);

5.Can be designed to meet special working environment such as high temperature.
